Table 6-1 lists the RS-232 command set. The “Parameter (min/max)” column shows the
valid parameter ranges, or “NA” for commands that take no parameters.
When you enter a valid command, the DHD Controller executes it and acknowledges it
with a plus sign on the command line (+ >). When you enter an invalid command – one
that is misspelled or followed by values outside the valid range for that command – the
DHD Controller ignores it and returns a minus sign (- >).
Table 6-1. Serial Commands
Command
Parameter
(min/max)
Value
Stored?
Description
Power On/Off Commands
OFF NANATurns display off
ON NA NA Turns display on
POWER 0/1 NA Turns display on and off
POWER? NA NA Returns power status
Input Selection Commands
COMPONENT NA YES Selects the Component input
COMPOSITE
or
COMPOSITE1
NA YES Selects the Composite 1 video input
COMPOSITE2 NA YES Selects the Composite 2 video input
COMPOSITE3 NA YES Selects the Composite 3 video input
HDMI1 NA YES Selects the HDMI 1 input
HDMI2 NA YES Selects the HDMI 2 input
HDMI3 NA YES Selects the HDMI 3 input
HDMI4 NA YES Selects the HDMI 4 input
HD1 NA YES Selects the RGB HD 1 input
HD2 NA YES Selects the RGB HD 2 input
INPUT? NA NA Returns active input
SCART NA YES Selects the SCART input
