External Control
Vistage™ Series Flat-Panel Display Installation/Operation Manual 61
PRE
L
IMINAR
Y
Aspect Ratio Commands
16:9 NA YES Selects the 16:9 aspect ratio
4:3 NA YES Selects the 4:3 aspect ratio
ASPECT? NA NA Returns current aspect ratio
CINEMA NA YES Selects the Cinema aspect ratio
LETTERBOX NA YES Selects the Letterbox aspect ratio
NATIVE NA YES Selects the Native aspect ratio
VIRTUALWIDE NA YES Selects the VirtualWide aspect ratio
VIRTUALCINEMA NA YES Selects the Virtual Cinema aspect ratio
Picture Adjust Commands
BRIGHTNESS -50/50 YES Sets a value for brightness
BRIGHTNESS? NA NA Returns brightness setting value
CHROMADELAY -7/7 YES Sets a value for input color chroma delay
CHROMADELAY? NA NA Returns input color chroma delay setting
COLOR -50/50 YES Sets a value for color
COLOR? NA NA Returns color setting value
CONTRAST -50/50 YES Sets a value for contrast
CONTRAST? NA NA Returns contrast setting value
FILMMODE 0/1 YES Sets Film Mode off (0) or on (1)
FILMMODE? NA NA Returns Film Mode setting
(0 = off; 1 = on)
FILTER 0/10 YES Sets a value for input color noise filter
FILTER? NA NA Returns input color noise filter setting
PHASE 0/31 YES Adjusts phase
PHASE? NA NA Returns phase setting value
SHARPNESS -50/50 YES Sets a value for sharpness
SHARPNESS? NA NA Returns sharpness setting value
TINT -50/50 YES Sets a value for tint
TINT? NA NA Returns tint setting value
Table 6-1. Serial Commands (continued)
Command
Parameter
(min/max)
Value
Stored?
Description
