SRC-3000B User’s Manual
8
The following table provides an overview of major key functions.
Name & Key
Icon
Function Setup Description
Device keys
Device setting
and LCD layout
Key: Enter device setting and
arrange the LCD touch screen layout
to correspond to your remote control.
(P.9)
You can also toggle device pages by
pressing the key again.
Code Setup key
Setup device
code, manually,
automatically or
by learning
function
Code: Enables you to enter pre-
programmed codes. (P.11)
Learn: Enables the remote to learn
codes from other remote controls
directly. (P.15)
Macro key
Setup Macro
Enables you to set Macro function.
(P.27)
You can also view the Macro setting
by pressing the key.
Delete key
Delete and reset
to default
Key: Erase key codes. Refer to P.19.
Bank: Erase device codes. (P.19)
Key & Bank: Reset to factory default.
(P.20)
System setup
key
Transmission,
backlight and
beep setup
Backlight: Setup backlight lasting
period and sensitivity. (P.29)
Code: Transmit all data. (P.27)
Beep icon: Turn the beep sound
on/off. (P.31)
After finishing setting, press the OK
key to confirm your decision.
Figure 3: Major Function Keys
The following chapters describe each function in detail.
