programming the system remote
|
4544
|
programming the system remote
learning new commands
To ‘learn’ new commands:
1. Select the device you wish to program by pressing the appropriate
REMOTE SELECTION key on the system-remote.
2. Place the system-remote and the remote of the unit you want to
control on a flat surface. Line up the remote controls head to head,
about 5 to 10cm (2 to 3in) apart.
3. Simultaneously press and hold the REMOTE SELECTION key
selected in step 1 and the ok key for about four seconds. The
learning status LED will turn yellow to indicate that the Remote is
now in learning mode
(1)
.
4. Press and release the key on the system-remote which you want to
program
(2)
. The status LED will flash yellow.
5. Press and hold for approximately three seconds the key on the
original remote control which corresponds to the function you want
the system-remote to learn. The status LED will flash shortly in
green if the code is correctly understood. If it flashes red then you
need to restart with step 4 as the code was not understood by the
remote.
6. Release the key on the original remote and re-press and hold it for
approximately a further three seconds. If the learning process has
been successful, the status LED will flash green twice, then return to
yellow. If the LED flashes red you need to restart with step 4 as the
code could not correctly be interpreted by the remote.
Repeat steps 4 through 6 to program further keys.
1. The Remote will stay in learning mode for 20 seconds, after which it will return to normal operation mode if there have been no further
key presses
2. The macro keys m1 to m4 can be programmed with new commands, but if they are used for the macro feature (see ‘programming macro
features’) the new command will be over-ridden
cd dvd amp
av
REMOTE SELECTION
sat
tv vcr ld
pause
play
skip
+
record
skip
eject
---
stop
ok
return
cancel
LFE
LFE
---
+
r
e
w
f
f
d
vcr ldtvsat
REMOTE SELECTION
cd dvd amp
av
Programming the system-remote control
The system-remote comes preprogrammed and ready to use for the
following TAG McLaren Audio products:
• audio-visual processor theatre AV32R
•five-channel amplifier 100x5R and three-channel amplifier 250x3R
• dvd player DVD32FLR and DVD32R
Other devices which are not pre-programmed to work with the system-
remote will need to be ‘learnt’. To program the system-remote for other
devices, you will need the original remote control for the unit you wish
to control.
programming the system-remote
Some devices (other than those listed above) may partially work
with the system-remote as supplied. To check this, select the desired
unit using one of the REMOTE SELECTION keys and try pressing a
few of the keys. If the device responds as expected, you may only
need to edit the set-up for that unit by programming one or two
keys, as explained on the following pages, otherwise you will need
to program the Remote for all commands.
cd dvd amp
av
REMOTE SELECTION
sat
tv vcr ld
