connecting
|
1312
|
connecting
Using the cable supplied, connect the socket on the back of your DVD32FLR to
an AC supply outlet. The player will automatically enter standby when the
power is applied, press any button on the front panel or the system remote
(see ‘remote control’ on page 14) to bring it out of standby. The blue power LED will come
on, followed by ‘SELFTEST’ then the software version, shown on the front panel display.
Your DVD32FLR has three different types of video output; COMPONENT VIDEO
(1)
, S-VIDEO
(2)
and COMPOSITE VIDEO. By definition, Component video will give better quality than S-
Video, which in turn will give much better quality than Composite video. You should therefore
use the highest quality video type which your video display device or video processor can
support, and connect directly from your DVD32FLR using high quality video cables (for
example our F3-10-SVID S-Video cable or our F3-10-VID Composite/Component cable).
When the optional Progressive Scan Module PSM192 is fitted it provides progressively
scanned video outputs in digital form on the DVI connector and in analog form on the BNC
component connectors. The analog progressively scanned outputs can be configured as
component YPbPr or RGB format with sync on green.
If you use the DVD32FLR with the TAG McLaren AV32R you can also connect the output
labelled ‘sync’ on the AV32R to the input labelled T
2
Link in on your DVD32FLR using a high
quality analogue cable, such as our F3-10-ANA. This connection provides synchronisation
between the AV32R and DVD32FLR which, when enabled
(1)
, further enhances the sound
quality produced by the AV32R. The DVD32FLR will also work with your AV32R without this
connection so you could activate the T
2
Link at a later stage.
Your DVD32FLR is shipped with a shorting plug in the T
2
Link (Sync) input. It is recommended
that the shorting plug be left in place if no T
2
Link connection to the AV32R is made, for best
sound quality.
power connection
video display connection
surround sound (audio visual) processor connection
Your DVD32FLR has two types of digital output; Two coaxial SPDIF (called DIGITAL OUTPUT 1
and 2) and one OPTICAL. We recommend using one of the coaxial connections for best
sound quality. Using a high quality digital interconnect, such as our F3-10-DIG, connect the
DIGITAL OUTPUT 1 or 2 of your DVD32FLR to a digital input on your AV processor.
1. If you intend to use Component video for best video quality, the picture may appear in false colours until your DVD32FLR has been setup correctly
2. S-Video is also available on the Y (luminance) and Pb (chroma) ‘component’ connectors to achieve a higher quality S-Video connection (compared
to the standard S-Video connector)
TAGtronic Synchronisation Link (T
2
Link)
1. Refer to the AV32R user manual for instructions on how to enable the T
2
Link
ATTENTION:
Remove the shorting plug when using the TAGtronic Synchronisation Link,
otherwise the link will not function.
