Tascam DR-70D VCR User Manual



40
TASCAM DR-70D
12 – Specifications
Requirements for connected
computers
Check the TEAC Global Site (http://teac-global.com/) for the
latest information about supported operating systems.
8
Windows PC
Pentium 300 MHz or faster
128 MB or more memory
USB port (USB 2.0 recommended)
8
Mac
Power PC, iMac, G3, G4 266 MHz or faster
64 MB or more memory
USB port (USB 2.0 recommended)
8
Recommended USB host controller
Intel chipset
8
Supported operating systems
Windows XP, Windows Vista, Windows 7, Windows 8
(including 8.1)
Mac OS X 10.2 or newer
General
8
Power
4 AA batteries (alkaline or NiMH)
USB bus power from a computer
AC adapter (TASCAM PS-P515U, sold separately)
Using an external battery pack (TASCAM BP-6AA, sold
separately)
8
Power consumption
5.0W (maximum)
8
Current consumption (USB bus power)
1 A (maximum)
8
Battery operation time (continuous operation)
Using alkaline batteries (EVOLTA)
Format
Operation
time (in hours:
minutes)
Note
Recording 2ch
44.1kHz/16-bit WAV
files
About 6:00
When XLR/TRS
input selected
(phantom power
not used)
Recording 2ch
44.1kHz/16-bit WAV
files
About 3:30
When XLR/TRS
input selected
(phantom power
used)
Recording 2ch
44.1kHz/16-bit WAV
files
About 11:00
When 3/4 MIC
input (built-in mic)
selected
Using NiMH battery (eneloop)
Format
Operation
time (in hours:
minutes)
Note
Recording 2ch
44.1kHz/16-bit WAV
files
About 6:15
When XLR/TRS
input selected
(phantom power
not used)
Recording 2ch
44.1kHz/16-bit WAV
files
About 3:15
When XLR/TRS
input selected
(phantom power
used)
Recording 2ch
44.1kHz/16-bit WAV
files
About 10:30
When 3/4 MIC
input (built-in mic)
selected
Using NiMH battery (eneloop-pro)
Format
Operation
time (in hours:
minutes)
Note
Recording 2ch
44.1kHz/16-bit WAV
files
About 7:45
When XLR/TRS
input selected
(phantom power
not used)
Recording 2ch
44.1kHz/16-bit WAV
files
About 4:45
When XLR/TRS
input selected
(phantom power
used)
Recording 2ch
44.1kHz/16-bit WAV
files
About 14:15
When 3/4 MIC
input (built-in mic)
selected
8
Battery operation time (continuous operation) when
using TASCAM BP-6AA (sold separately)
Using alkaline batteries (EVOLTA) + BP-6AA (EVOLTA)
Format
Operation
time (in hours:
minutes)
Note
Recording 2ch
44.1kHz/16-bit WAV
files
About 13:00
When XLR/TRS
input selected
(phantom power
not used)
Recording 2ch
44.1kHz/16-bit WAV
files
About 7:30
When XLR/TRS
input selected
(phantom power
used)
Recording 2ch
44.1kHz/16-bit WAV
files
About 25:30
When 3/4 MIC
input (built-in mic)
selected
Using NiMH batteries (eneloop pro) + BP-6AA (EVOLTA)
Format
Operation
time (in hours:
minutes)
Note
Recording 2ch
44.1kHz/16-bit WAV
files
About 12:45
When XLR/TRS
input selected
(phantom power
not used)
Recording 2ch
44.1kHz/16-bit WAV
files
About 7:45
When XLR/TRS
input selected
(phantom power
used)
Recording 2ch
44.1kHz/16-bit WAV
files
About 24:45
When 3/4 MIC
input (built-in mic)
selected
Using NiMH batteries (eneloop pro) + BP-6AA (EVOLTA)
Format
Operation
time (in hours:
minutes)
Note
Recording 2ch
44.1kHz/16-bit WAV
files
About 14:30
When XLR/TRS
input selected
(phantom power
not used)
