Copyright © 2005 TOSHIBA CORPORATION. All rights reserved.
(E) 56/62/72MX195
Viewing the CableCARD™ menu
A CableCARD
™
enables you to view encrypted digital channels.
See page 14 for connection and subscription information.
After the CableCARD
™
is inserted, a CableCARD
™
option
appears in the Applications menu, with informational screens
provided by your digital CableCARD
™
service (see illustrations
below).
CableCard Connected -- Acquiring
channel information.
CableCard services will only operate
with cable signal connected to Antenna 1.
To view the CableCARD
™
menu:
1. Press MENU and open the Applications menu.
2. Highlight CableCARD
™
and press •.
3. Press z or y to select one of the side menu items and press
ENTER to display the information.
Navigate
Select
Back Exit
CH RTN
EXIT
Applications
TV Guide On Screen
Audio Player
Picture Viewer
Digital CC/Audio Selector
IP Service
Conditional Access
CableCARD(tm) Status
Network Setup
CableCARD(tm) Pairing
CableCARD
Note: The CableCARD
™
menu is for informational purposes
only and has no user-adjustable options.
Chapter 6: Setting up your TV
Setting the Quick Restart™ feature
With the Quick Restart
™
feature set to ON, the TV will stay in
Shutdown mode for several minutes after the TV is turned off
(see Notes below).
If the TV is turned on from Shutdown mode, the full picture
appears immediately.
To set the Quick Restart
™
feature:
1. Press MENU, and then press x or • until the Setup menu
appears.
2. Highlight Quick Restart and press •.
3. Press z or y to select either On or Off.
Navigate
Select
Back Exit
CH RTN
EXIT
Setup
Auto
PC Settings
HDMI 1 Audio
Auto
Auto
Auto
Auto
2 Sec
HDMI 2 Audio
Slide Show Interval
15 min
AVHD Skip Time
1
Gray Level
On
Quick Restart
On
Off
Note:
If Quick Restart is set to Off and you turn off the TV, it can take
several seconds for the picture to appear when you turn on the TV
again. See “IMPORTANT NOTICE ABOUT HOT LAMP RESTART,”
below.
If Quick Restart is set to On and you turn off the TV, the following
will occur for a few minutes:
• The screen (lamp) lights dimly.
• The fans continue to run.
This is a function of the Quick Restart Shutdown mode and is not a
TV malfunction. If you do not prefer this, set the Quick Restart
feature to Off.
When the Quick Restart feature is set to Off, if you repeatedly turn
the TV on and off in a short period of time, the useful service life of
the lamp may be shorter than the average useful service life. See
page 128.
IMPORTANT NOTICE ABOUT
“HOT LAMP RESTART”
When the TV has been powered on long enough for the lamp unit
to get hot, it may take several minutes for the picture to appear
on-screen in the following situations:
• When the Quick Restart™ feature is set to OFF and you turn
the TV off and then on again within a few minutes.
• If the TV is on when a short-term power failure, power surge,
or other similar power failure occurs, such that the TV loses
and regains power within a few minutes.
This is a property of DLP TV lamp technology
and is NOT a sign of malfunction.
If this occurs, the yellow LED on the TV front panel will blink (and
the blue LED will be lit solid) until the TV is finished restarting the
lamp and the normal picture appears. If BOTH yellow and blue
LEDs are blinking at a one-second rate, you will need to turn the
TV off and then on again to restart the lamp.
