SPECIFICATIONS
General
Power requirements AC120 V, 60 Hz
Power consumption 17 W (standby: 2.5 W)
Weight 5.3 lbs ( 2.4 kg )
Dimensions (width x height x depth) 16.6” x 2.4” x 9.8” (420 x 59.0 x 247 mm)
Operating temperature 41 °F to 104 °F (5 °C to 40 °C)
Operating humidity Less than 80% (no condensation)
TV system NTSC TV standard
Recording
Recording format VR (video recording) format
Video format
+VR format
Recording discs DVD-Rewritable/-Recordable, DVD+Rewritable/+Recordable
Video recording format
Sampling frequency
Compression format
13.5 MHz
MPEG
Audio recording format
Sampling frequency
Compression format
48 kHz
Dolby Digital/LPCM (XP Recording mode only)
Input / Output
Video input
Input level
Jacks
Input 1 (rear), 2 (front)
1 Vp-p (75Ω)
RCA jack
Video output
Output level
Jack
Output 1 (rear)
1 Vp-p (75Ω)
RCA jack
S-video input
Y (luminance) - Input level
C (color) - Input level
Jacks
Input 1 (rear), 2 (front)
1 Vp-p (75Ω)
286 mVp-p (75Ω)
4 pin mini DIN
S-video output
Y (luminance) - Output level
C (color) - Output level
Jack
Output 1 (rear)
1 Vp-p (75Ω)
286 mVp-p (75Ω)
4 pin mini DIN
Component video output
Output level
Jacks
Output 1 (rear)
Y: 1.0 Vp-p (75Ω), P
B/CB, PR/CR: 0.7 Vp-p (75Ω)
RCA jacks
HDMI output
Jack HDMI jack
Audio input
During audio input
Jacks
Input 1 (rear), 2 (front) L/R
2 V rms (input impedance: more than 22 kΩ)
RCA jacks
Audio output
During audio output
Jacks
Output 1 L/R (rear)
2 V rms (output impedance: less than 1 kΩ)
RCA jacks
Digital audio output
Output level
Jack
Output 1 (rear) COAXIAL
500 mVp-p (75Ω)
RCA jack
DV input
Jack
IEEE 1394
DV input jack (4 pin)
• This model complies with the below specifications.
• Designs and specifications are subject to change without notice.
• This model may not be compatible with features and/or specifications that may be added in the future.
