CONNECTIONS
Digital Audio Connection
Coaxial Cable Connection
HDMI Audio Connection
To set up “Dolby Digital”, refer to pages 81 and 83-85.
Setting in the Setup Menu
Actual Audio Output
Audio Format (disc)
Dolby Digital Setting
of this unit (refer to
page 85)
DTS Setting of
this unit
(refer to page 85)
HDMI OUT
DIGITAL AUDIO
OUTPUT
Dolby Digital
Stream — Dolby Digital Dolby Digital
PCM — 2 channel PCM 2 channel PCM
DTS
— ON DTS DTS
— OFF No output No output
LPCM
Stream ON 2 channel PCM 2 channel PCM
PCM OFF 2 channel PCM 2 channel PCM
Multi Channel Digital Audio Setting
COAXIAL
DIGITAL AUDIO OUTPUT
PCM / BITSTREAM
COAXIAL
rear of this unit
Dolby Digital decoder
digital audio
coaxial cable
digital audio
coaxial input jack
IN
Y
PR/CR
PB/CB
L
R
VIDEO
OUT
S-VIDEO
AUDIO OUT
HDMI OUT
COMPONENT
VIDEO OUT
VIDEO
IN
L
R
AUDIO IN
(L1)
OUT
S-VIDEO
COAXIAL
DIGITAL AUDIO OUTPUT
PCM / BITSTREAM
HDMI OUT
rear of this unit
AV receiver / amplifier with an HDMI input jack
HDMI IN
IN
Y
PR/CR
PB/CB
L
R
VIDEO
OUT
S-VIDEO
AUDIO OUT
COMPONENT
VIDEO OUT
VIDEO
IN
L
R
AUDIO IN
(L1)
OUT
S-VIDEO
COAXIAL
DIGITAL AUDIO OUTPUT
PCM / BITSTREAM
HDMI OUT
HDMI cable
No supplied cables are used in these connections:
Please purchase the necessary cables at your local store.
To set up “HDMI Audio”, refer to pages 82 and 91-92.
