Chapter 2 105
One-Button Measurement Functions
Trace/View (ACP Measurement)
One-Button Measurement Functions
2.4 Trace/View (ACP Measurement)
If ACP has been selected in the Measure menu of the Spectrum Analysis mode, this key
displays the appropriate
Trace/View menu for the adjacent channel power (ACP)
measurement.
Displays menu keys that enable you to set how trace information is stored and displayed.
Key Path: Front-panel key
Factory Preset: Spectrum
History: Added with PSA firmware revision A.02.00
Remote Command:
There is no equivalent remote command for this function.
2.4.1 Spectrum
Pressing Spectrum selects the spectral display of the measurement.
NOTE PSA Only: Spectrum is disabled when using the Fast Method.
Key Path:
Trace/View
Factory Preset: Spectrum
History: Added with PSA firmware revision A.02.00
Added with ESA firmware revision A.07.00
Remote Command:
There is no remote command for this function.
2.4.2 Bar Graph
Pressing Bars turns the graphic bar display on or off.
Key Path:
Trace/View
Factory Preset: Spectrum
History: Added with PSA firmware revision A.02.00
Added with ESA firmware revision A.07.00
