162 Chapter 2
One-Button Measurement Functions
Meas Setup (Multi-Carrier Power—MCP)
One-Button Measurement Functions
Key Path: Meas Setup, Carrier Setup, Configure Carriers
Dependencies/
Couplings: All keys available on the Configure Carrier key menu are coupled to this
key.
State Saved: Saved in instrument state.
Factory Preset: 1
Knob Increment: 1
Step Key
Increment: 1
Range: 2 to 12
History: Added with ESA firmware revision A.09.00.Added with PSA firmware
revision A.03.00.
Remote Command:
There is no equivalent remote command.
2.16.3.4.2 Carrier Pwr Present
Press
Carrier Pwr Present (Yes) to specify carriers which have power present. First, press
the
Carrier key and select the carrier number you wish to define, using the Step Keys (⇓ ⇑),
the knob, or the numeric keypad. (The carrier number selected is shown on the
Carrier key.)
Then toggle the
Carrier Pwr Present key to indicate either yes or no.
If a carrier is defined as having no power present, the power displayed will be relative to
the reference carrier. If a carrier is defined as having power present, the absolute power
will be displayed.
Carriers with power present are included in the total carrier power result.
Key Path:
Meas Setup, Carrier Setup, Configure Carriers
Dependencies/
Couplings: This key assigns a value (yes or no) to the carrier number displayed on the
Carrier key.
State Saved: Saved in instrument state.
Factory Preset: YES, YES, YES, YES
Range: Yes or No
History: Added with ESA firmware revision A.09.00.Added with PSA firmware
revision A.03.00.
Remote Command:
[:SENSe]:MCPower:CARRier:LIST:PPResent YES|NO
