22
ENGLISH
S-VIDEO
OUT
DIGITAL
OUT
AUDIO
OUT1
DIGITAL OUT
VIDEO OUT
S-VIDEO
COMPONENT/
PROGRESSIVE SCAN
COAXIAL
OPTICAL
L
R
AUDIO
OUT2
L
R
Y
COMPONENT
VIDEO OUT/
PROGRESSIVE
SCAN
VIDEO
OUT
P
R
/C
R
P
B
/C
B
F Connecting to a TV and an AV receiver equipped with a Dolby Pro Logic decoder
Set the setup menu correctly after
connecting
Set the "TV Aspect" in the setup menu according to the TV
connected to the unit as follows:
(See "Changing Setup Values" on page 46 for details.)
TV Aspect
When the TV has a conventional 4:3 screen:
4:3 Letterbox or 4:3 Panscan
When the TV has a wide 16:9 screen:
16:9 Wide
TV
yellow
to the video input jack (yellow)
Video cord (supplied)
yellow
Rear of the unit
to VIDEO OUT jack (yellow)
red
white
to an AC outlet
Audio cord (supplied)
to the audio input jacks
(L/white, R/red)
Receiver equipped
with a Dolby Pro
Logic decoder
Front speaker (L)
Surround speaker (L)
Center speaker
Surround speaker (R)
to AUDIO OUT 1*
L (white)/R (red) jacks
Front speaker (R)
Connections (continued)
* AUDIO OUT 2 L/R jacks are also available.
