21
3.1 Menu Function
Use remote control to navigate in the OSD menu. The red frame turns yellow when you are
making a selection.
Each time you change the video display output or video system (NTSC/PAL), the power
must be turned off and on to reset the DVR unit.
OSD MENU Description
MAIN MENU
CAMERA/RECORD
SCHEDULE
EVENT SETUP
DISPLAY
STORAGE
SYSTEM
CAMERA/RECORD SETUP
Configure camera parameters, name and PTZ camera.
CAMERA / RECORD SETUP
GENERAL
CHANNEL SETTING
PTZ
CHANNEL NAME
GENERAL SETUP
GENERAL SETUP
RECORD MODE
TIME STAMP
DVR NAME
WATERMARK
AUTO RECORD
CIF
COMPANY
RECORD MODE
Three type of recording mode -- D1/CIF/D1 Enhance.
Under D1 mode, the video recording is in full screen resolution
and takes turns from one channel to the next one when Auto
Scan enables. Each channel is recorded only at a maximum
frame rate of 15fps. User can switch to view the video in single
full screen or QUAD screen.
Whereas in CIF mode, video recording is at a lower resolution,
but each video is recorded in 30fps/25fps (NTSC/PAL). User
can switch to view the video in single full screen or QUAD
screen.
In D1 Enhance mode, video is recorded in 30/25fps
(NTSC/PAL). User also can switch to view the video in single
full screen or QUAD screen.
DVR NAME
Assign a name for the DVR unit. Maximum is 12 characters that
can include A~Z, 0~9, !, “, #, $, %, &, ‘, (, ), *, +, -, /, :, ;, <. >, ?,
@, and space.
TIME STAMP
Enable/disable the time and date display on the each channel.
