Chapter 5: EDID Configuration (Local Unit Only)
5. EDID Configuration (Local Unit Only)
In some cases, display problems may occur because of incorrect EDID
communication between the display monitor and the unit or inappropriate EDID
data programmed by display manufacturers. Press the “EDID Config” button on the
top panel of the local unit to enable the unit to configure EDID from EDID-compliant
monitors or have the system automatically optimize all valid (audio and/or video)
outputs. Table 5-1 summarizes EDID Configuration.
Table 5-1. EDID configuration.
EDID Mode Video EDID Audio EDID
Auto mixing and
EDID Config
Auto mixing: Min. (of all)
Automatically optimize all
valid (video) outputs for
minimum requirement
Config local monitor
(audio) EDID and all
connected monitors use
the configured (audio)
EDID
EDID Config
Config local monitor
(video) EDID and all
connected monitors use
the configured (video)
EDID
Config local monitor
(audio) EDID and all
connected monitors use
the configured (audio)
EDID
Auto mixing
Auto mixing: Min. (of all)
Automatically optimize all
valid (video) outputs for
minimum requirement
Auto mixing: Min. (of all)
Automatically optimize all
valid (audio) outputs for
minimum requirement
NOTE: The default mode is auto mixing.
