Page 8
Chapter 2: Overview
2. Overview
2.1 Introduction
The 3D HDMI Fiber Extender consists of a Local and a Remote Unit. It enables users
to extend video, 3D video (1080i), and audio signals up to 5120 feet (1600 m,
approx. 1 mi.) from an A/V source via duplex multimode fiber optic cable, or up to
2560 feet (800 m, approx. 0.5 mi., 1080p) using duplex multimode fiber optic cable.
The HDMI digital display supports up to the maximum resolution of full HD (1920 x
1080)/WUXGA and (1920 x 1200)/UXGA (1600 x 1200), along with audio channels.
The EDID Config function enables the best video presentation. Optionally, the 3D
HDMI Fiber Extender can configure audio or audio and video EDID via push-button
commands.
Use the Fiber Extender in applications that require greater distance, high speed
transmission, real-time high video resolution, security, and noise immunity. Its
scalable design enables your enterprise to grow.
2.2 Features
• Extends the video signal up to 2560 feet (800 m), approx. 0.5 mi. (1080p)
or 5120 feet (1600 m), approx. 1 mi. (1080i) over multimode fiber.
• Supports pure digital transmission with zero compression.
• EDID Config function increases display capability
• Includes selectable EDID (audio) functions for multimedia system integration
• IR extending function is available (38 kHz only)
• Complies with HDMI 1.3b specification
• Complies with 3D-video, HDCP compliant, and Blu-ray ready
• Software and driver installation NOT required
2.3 What’s Included
Your package should contain the following items. If anything is missing or damaged,
contact Black Box Technical Support at 724-746-5500 or info@blackbox.com.
• 3D HDMI Fiber Extender Local Unit
• 3D HDMI Fiber Extender Remote Unit
• (2) Power supplies with snap-on power plug
• IR collector
• IR emitter
• 2-m SC-SC duplex 50-/125-micron patch cord
• (2) sets of 4 foot pads
