Chapter 2: Overview
• (10) small screws
• (8) small rare earth magnets for mounting
• Quick Install Guide
2.4 System Requirements
You will need to supply the following items:
• HDCP compliant monitors with HDMI interface for the HDCP video source
• HDMI cable
2.5 Hardware Description
Figures 2-1 shows the local and remote units. Table 2-1 describes their components.
L1 L2 L3
L5
L4
L8 L6 L7
L8
R1 R2 R3
R5
R4
R6 R7
Figure 2-1. Local (L) and Remote (R) units.
