Clarion TVX5653 Flat Panel Television User Manual



15
English
Owners Manual
TVX5653
TV Mode Operations
Manual memory function
1) Press the joystick # up (w) or down (z) to
select TV1 or TV2.
2) Press the joystick # to the left (Å) or right
(Î) to select the channel to be preset.
3) Hold down for about 2 seconds the preset
channel button (4 to 9) in which the station
is to be stored. The new channel now being
received is stored in the memory.
*Upon completion of the memory operation, the
channel display at the top left of the screen
turns red.
Note:
The memory contents are returned to the
default settings when the battery is replaced or
the power supply is otherwise suspended.
Preset scanning
1) Press the SHIFT button 3 to display the
menu screen.
Checking out the channels
1) Press the CH (channel) button 0.
The channel currently being received will be
displayed for about 5 seconds, together with
the number of the preset button and the
screen display mode.
Permanently displaying the channel
1) Press the SHIFT button 3 to display the
menu screen.
*The menu screen remains displayed for about
5 seconds.
*Perform the next operation while the menu
screen is displayed.
2) Press the DISP (display) button 4.
The current channel is now permanently dis-
played on the screen.
*The menu screens DISP indicator will
change to red.
Note:
When the channel non-permanent display
mode has been set, the reception channel is
displayed for about 5 seconds when the TV
band is changed and when tuning.
3) To clear the channel display, first display the
menu screen again, and then press the DISP
(display) button 4.
*The menu screens DISP indicator will
change to white.
Selecting the FM modulator fre-
quency
The FM modulator frequency can be set only in
the TV mode.
The factory setting is 88.3 MHz.
1) Press the TV/CD button 2 to select the TV
mode.
2) Press the SHIFT button 3 to display the
menu screen.
*The menu screen remains displayed for about
5 seconds.
*Perform the next operation while the menu
screen is displayed.
2) Press the PS (preset scan) button 5.
The stations stored in the preset channels are
received in sequence at intervals of about 5
seconds per station.
3) To release the preset scanning, display the
menu screen, and press the PS button 5.
Preset selection
1) Press the joystick # up (w) or down (z) to
select TV1 or TV2.
2) Press one of the preset channel buttons (4
to 9).
The station in the channel which is stored in
the memory is now tuned in.
*The menu screen remains displayed for about
5 seconds.
*Perform the next operation while the menu
screen is displayed.
