Daewoo DT-42A1 Flat Panel Television User Manual



19
19
58
20
43
53
50
46
69
70
51
55
14
Remote Control
* The number in ( ) indicates the page in which
the function of each button is explained in detail.
TV/VCR/DVD/SAT/CATV
Channel Number (0-9)
Use to select channel directly (0-9).
RECALL
Indicates the current state and resolution.
TV
Press to select TV Mode.
COMPONENT, PC/DVI
Press to select COMPONENT
or PC/DVI modes.
Menu button
Used to display a main menu.
Previous Program button
It returns to previous channel.
Mute button
Mute sound.
Picture Mode button
Whenever pressing the button, it cycles in the
following order: Normal - Dynamic - Cinema - User
Sound Mode button
Whenever pressing the button, it cycles in the
following order: Normal - Movie - Music - News - User
Sound Effect button
Press to use a spatial sound effect
Power button
Pressing the power button of the TV allows
the display to be put in standby. (A red light is shown in the remote
control sensor.) At this time, if you press the power button of the remote
control, the display is turned ON (And shows a green light in the sensor).
Still
Used to view a still picture whilst watching
moving images.(Sound can be heard.)
AV
Press to selet AV modes.
It changes in the following sequence
AV1 ->AV2 ->AV3
PR button /: Adjusts the channel.
Volume button / : Adjusts the volume.
Screen Size button
Adjusts the size of the screen
(16:9, 4:3, Panorama etc.)
Sleep Timer
Each time you press this button, a different input mode appears. The
sequence is as follows:
15Min. -> 30Min. - > 60Min. -> 90Min. -> 120Min. -> OFF
After the time is selected, the TV automatically goes into a stand-by state.
Teletext Function
I – II
- Selects the language during dual language
broadcast.
- Selects mono sound during stereo
broadcast.
PIP Mode Function
VIDEO/DVD Function
When using remote control:
Be sure not to allow the remote control to drop or to become wet.
Keep it away from hot or moist locations.
Installing the batteries in your remote control:
Push to open the cover of the remote control
Put the batteries in the battery cell after checking the polarities, and then
shut the cover.
Note
• Use two “AAA” batteries.
• Be sure to use replacement batteries of the
same type as the original ones.
• The life of a battery depends on how much
it has been used.
