Daewoo DT-42A1 Flat Panel Television User Manual



AV1 AV2
AV(S)3
Component 1 Component 2
33
NOTES:
1) Y/Cb/Cr, which stands for component video DVD player’s
output can also be written as Y/B-Y/R-Y, Y/Pb/Pr depending on
the kinds of DVD model.
2) The way of connecting the DVD to the PDP is as follows:
Y <---> Y Cb <---> Pb, B-Y, Cr <---> Pr, R-Y
3) The DVD output can be Video, S-Video or Component Video
depending on the DVD model. There are various output
modes, so be sure to check when you purchase it.
4) When connecting S-Video and Video simultaneously, only SVideo
will be displayed on the screen as it takes precedence.
Input Select
• Select [Component 1 or Component 2,
AV1(Scart), AV2(Scart) or AV3(S-Video)] by
pressing the [COMPONENT] or [AV] button of
the remote control or the “INPUT SELECT” in
keypad of the PDP unit.
• Each time you press the [COMPONENT] or
[AV] button, a different input mode appears.
The sequence is as follows:
3
Select the Desired Title and Function
• Select the desired title and function by
using the remote control of the DVD.
4
C
O
M
P
O
N
E
N
T
AV
• [COMPONENT] button
• [AV] button
