CTV Antenna Connection
CTV Antenna Connection
When a coaxial cable is used
TV antenna installation may be found in most.
Plug the coaxial cable to the antenna socket, and fix it firmly.
Antenna socket on the wall Antenna socket at the back of the
PDP unit.
When a feeder cable is used
Antenna socket
on the wall
Antenna socket at the back of the
PDP unit.
Feeder cable connection with the combining adapter
ANT/KABEL 1
Antenna Connection
Antenna Connection
Coaxial cable
ANT/KABEL1
