VCZ625 29
Changing Initial Settings such as Menu Language, etc.
Setting up the angle mark display
You can set up so that the angle mark appears
on scenes where the angles can be switched.
1. Following the steps 1 to 4 in “Selecting the
monitor menu”, select “ANGLE MARK” from
“GENERAL SETUP”.
2. Press the “ ” or “ ” button to select ON or
OFF.
3. Press the [ENT] button.
The factory default setting is OFF.
Setting up the output mode for
audio signals
1. Following the steps 1 to 4 in “Selecting the
monitor menu”, select “AUDIO OUT” from
“GENERAL SETUP”.
2. Press the “ ” or “ ” button to select
ANALOG, SPDIF/RAW, or SPDIF/PCM.
● ANALOG:
Outputs analog audio signals through RCA
connection.
● SPDIF/RAW:
Outputs 5.1ch digital signals through optical
connection.
PCM audio signals are output downsampling
the signal from 96 KHz to the lower sampling
rate, 48 KHz.
● SPDIF/PCM:
Outputs 2ch digital signals through optical
connection.
PCM audio signals are output downsampling
the signal from 96 KHz to the lower sampling
rate, 48 KHz.
3. Press the [ENT] button.
The factory default setting is ANALOG.
Setting up the subtitle display
1. Following the steps 1 to 4 in “Selecting the
monitor menu”, select “CAPTIONS” from
“GENERAL SETUP”.
2. Press the “ ” or “ ” button to select ON or
OFF.
3. Press the [ENT] button.
The factory default setting is OFF.
