VCZ625 35
11. SPECIFICATIONS
DVD player section
System: Digital Versatile Disc System with CDDA
Capable
Usable Discs: DVD Video Disc, Compact Disc
Frequency Response: 20 Hz to 20 kHz (± 1 dB)
Signal to Noise Ratio: 90 dB
Distortion: 0.02%
Channel Separation: 80 dB
Analog audio output 1.8 Vrms
General
Source unit
Power Supply Voltage:
14.4 V DC (10.8 to 15.6 V allowable)
Ground:Negative
Current Consumption : Less than 1.5 A
Weight: 3.5lb. (2.2 kg)
Dimensions:
9-1/16” Width X 3-1/4” Hight X 7-3/16” Depth
(230 mm Width X 83 mm Hight 183 mm Depth)
Remote control unit
Weight: 1oz. (130 g) (including battery)
Dimensions:
2-1/8” Width X 1-1/16” Hight X 6-1/8” Depth
(54 mm Width X 27.2 mm Hight 155 mm Depth)
Remote control receiver section
External dimensions:
7/8” Width X 1-5/8” Hight X 1/2” Depth
(22 mm Width X 41.5 mm Hight 13.3 mm Depth)
Mass: 33 g
Note:
• Specifications and design are subject to change
without notice for further improvement.
List of accessories
VCZ625............................................................1
Owner’s manual ...............................................1
Installation instructions ....................................1
Warranty ..........................................................1
Ce-NET cable (5 m).........................................1
Power cord (5 m) .............................................1
Parts bag
• Installation nut (M5) ....................................4
• Installation bolt (M5 x 8) .............................4
• Clamping band............................................2
Bracket with bolt ............................................. 2
Bracket for installing the main unit
(for vertical installation) .............................. 2
(for horizontal installation) .......................... 2
Batteries for remote control unit (type AA) ........2
Remote control unit .........................................1
Double sided tape for securing brackets.........2
Magazine (CAA-397) .......................................1
Remote control receiver ..................................1
RCA pin cord (audio), 5 m...............................1
RCA pin cord (video), 5 m ...............................1
Ferrite core ......................................................1
