Dynex DX-19L200A12 Flat Panel Television User Manual



40
SpecificationsDX-19L200A12
Specifications
Specifications are subject to change without notice.
Warranty
Dimensions and weight
Screen
?
Display resolutions/VGA scan rates
Tuner
Inputs
Outputs
Audio
Power
Miscellaneous
Parts: 1 year
Labor: 1 year
Without stand:
18.58 × 12.91 × 2.52 in.
(47.2 × 32.8 × 6.4 cm)
With stand:
18.58 × 14.25 × 6.85 in.
(47.2 × 36.2 × 17.4 cm)
Without stand:
6.9 lbs. (3.1 kg)
With stand:
7.1 lbs. (3.2 kg)
Screen size measured
diagonally
18.5"
Display type LCD
Panel 60 Hz vs.120 Hz 60Hz
Display resolution 720p
Panel resolution 1366 (H) × 768 (V)
Aspect ratio 16:9
Contrast ratio (typical)–panel 1000:1
Brightness (center typical)
cd/m2
210 nits
Comb filter 3d y/c digital
Response time 5ms (Tr + TF)
Horizontal viewing angle 170
Vertical viewing angle 160
HDMI Suggested Resolutions: 1080p,
1080i, 720p, 480p, 480i
Component video Suggested Resolutions: 1080i,
720p, 480p, 480i
PC/VGA Suggested scan rates:
VGA: 640 × 480 60/72/75Hz
VGA: 720 × 400 70Hz
SVGA: 800 ×600 56/60/72/75Hz
XGA: 1024 × 768 60/70/75Hz
WXGA: 1280
×
768 60Hz
WXGA: 1280× 720 60Hz
WXGA: 1360× 768 60Hz
Analog NTSC
Digital ATSC, 8-VSB, Clear-QAM
HDMI/DVI 1 (ba ck)
E - E D ID c om p l i a nt
HDCP compliant
Component video 1 (back)
Composite video 1 (back)
Shared audio (component
and composite)
Yes
S-Video No
PC/VGA 1 (back)
3.5mm PC audio input 1 (back)
USB Yes - for firmware
upgrade only
Video No
Analog audio No
Digital audio 1 (back)
WiFi No
Ethernet No
Headphone 1 (back)
Simulated Surround Sound Yes
Sound Leveler No
Watts/channel 2W x 2
Number of speakers 2
Power consumption On: 29W
Standby: 0.3W
Power input 120V/60Hz
OSD languages English, French, Spanish
INlink No
Game Mode No
ENERGY STAR qualified Ye s
Internet connectable No
TV base screws M3 × 8mm (2 pcs)
M4 × 25mm (2 pcs)
V-Chip Yes
Sleep timer Ye s
Channel labeling Yes
VESA mount (mm)
(horizontal × vertical)
100 × 100
Note
The length of the wall-mount screws vary depending
on the wall-mount bracket you purchased. See the
instructions that came with the wall-mount bracket
for screw lengths.
DX-19L200A12_11-0606 MAN_ENG_V1.book Page 40 Thursday, November 3, 2011 10:06 AM
