Installing and removing the standDX-32L130A10
Installing and removing the
stand
You must install your TV into the stand for it to stand
upright on a cabinet or other flat surface. If you
intend to mount your TV on a wall or other vertical
surface, you must remove the stand column.
Warning: Before attempting assembly or removal of the
stand, unplug the AC power cord.
Cautions:
Read these instructions thoroughly before attempting this
installation.
Make sure that you handle your TV very carefully when
attempting assembly or removal of the stand. If you are
not sure of your ability to do this, or to use the tools
necessary to complete this job, refer to a professional
installer or service personnel. The manufacturer is not
responsible for any damages or injuries that occur due to
mishandling or improper assembly.
When using a table or bench as an aid to assembly, make sure
that you place the TV on a soft cushion or covering to
prevent accidental scratching or damage to your TV’s
finish.
The speaker is not intended to support the weight of your TV.
Do not move or handle your TV by the speaker. This can
cause damage to your TV that is not covered by the
manufacturer’s warranty.
Installing the stand
To install the stand:
1 Remove the stand from the box and place it on
a table or bench.
2 Lay your TV flat, screen down, on a clean, flat,
stable surface, such as a tabletop. Make sure
that you place it on a soft cushion or cloth so
that your TV is not scratched.
3 Align the base with the bottom of the TV, then
secure the base to the TV with the four M5XL
14 mm screws provided.
4 Set your TV upright on a stable surface.
Removing the stand
To remove the stand from the stand column:
1 Lay your TV face down on a table or bench.
Make sure that you place it on a soft cushion or
cloth so that your TV is not scratched).
2 Remove the four M5XL 14 mm screws securing
the base to the TV, then remove the base.
Installing a wall-mount bracket
If you want to attach the TV to a wall-mount bracket
(not provided), you should first remove the stand
pedestal if it is pre-attached (see above).
To attach your TV to a wall-mount bracket:
Warning: These servicing instructions are for use by qualified
service personnel only. To reduce the risk of hazards, do
not perform any servicing other than that contained in the
operating instructions unless you are qualified to do so.
Secure the wall-mount bracket to the back of
your TV using the four screws provided with the
bracket.
