14
Specifications
Specifications
Design and specifications are subject to change without notice.
Troubleshooting
Use the following checklist for troubleshooting when you have problems
with your television. Consult your local dealer or service outlet if
problems persist. Be sure all connections are properly made when using
with other units.
Power supply AC 120V, 60 Hz
Power Consumption
Operation 60 Watts
Standby 3 Watts
Chassis Construction
Chassis IC solid state
Weight 20.9 lbs. (9.5 kg)
Width 14-1/4 inches (362 mm)
Height 12-5/8 inches (320.5 mm)
Depth 14-3/16 inches (360 mm)
Inputs
VIDEO 1 V (p-p)/75 ohms
AUDIO 300 mV/47k ohms
Output
Audio power rating 1 Watt
Other
Antenna input VHF/UHF In 75 ohm coaxial
Speaker 3 inches (76.2 mm), full range, 8
ohms
Picture tube 13 inches (330.2 mm diagonal)
Horizontal resolution 260 lines
Receiving channels VHF 2-13
UHF 14-69
CABLE TV 01-97 (5A)-(A-3)
98-99 (A-2)-(A-1)
14-22 (A)-(I)
23-36 (J)-(W)
37-65 (AA)-(FFF)
66-125 (GGG)-(125)
Remote control Infrared, direct access
2 - AAA batteries
Problem Solution
Television does not
operate.
• Make sure the power cord is plugged in.
• Try another AC outlet.
• Power is off. Check fuse or circuit breaker.
• Unplug television for an hour, then plug it back in.
Poor sound or no
sound.
• Station or cable experiencing problems. Tune to
another station.
• Check sound adjustments (volume and mute).
• Check for sources of possible interference.
Poor picture or no
picture.
• Station or cable experiencing problems. Tune to
another station.
• Make sure channels are set into memory.
• Check antenna or cable connections. Adjust the
antenna.
• Check for sources of possible interference.
• Check picture control adjustments.
Poor reception on
some channels.
• Station or cable experiencing problems. Tune to
another station.
• Make sure channels are set into memory.
• Station is weak. Adjust the antenna to receive the
desired station.
• Check for sources of possible interference.
Poor color or no
color.
• Station or cable experiencing problems. Tune to
another station.
• Make sure channels are set into memory.
• Check picture control adjustments.
• Check antenna or cable connections. Adjust the
antenna.
• Check for sources of possible interference.
Picture wobbles or
drifts.
• Station or cable experiencing problems. Tune to
another station.
• Make sure channels are set into memory.
• Cable company is scrambling signal.
• Adjust antenna.
Digital
broadcasting
screen problem.
•Check antenna.
• Adjust antenna.
No CATV reception.
• Check all cable connections.
•Set TV CABLE menu option to the CABLE mode.
• Station or cable system problems. Try another
station.
Horizontal or
diagonal bars on
screen.
• Check antenna connections.
• Adjust or re-direct antenna.
• Check for sources of possible interference.
No reception above
channel 13.
• Make sure the TV CABLE menu option is in the
appropriate mode.
• If using an antenna, check the UHF antenna
connections.
No remote
operation.
• Batteries are weak, dead, or inserted incorrectly.
• Remote is out of range. Move closer to television
(within 15 feet).
• Make sure the remote is aimed at the sensor.
• Confirm there are no obstructions between the
remote and the television.
• Make sure the power cord is plugged in.
Television shuts off.
• No broadcast on tuned station.
• Sleep timer is set.
• Power interrupted.
Closed Caption is
not activated.
• Television station experiencing problems or
program is not closed captioned. Try another
channel.
• Check cable connection or VHF/UHF antenna.
Reposition or rotate antenna.
• Set closed caption decoder in the menu.
Display is not
shown in your
language.
• Select correct language in the menu options.
