Setting up the DVD player
55
SCART version
Use this output To connect to this
SCART OUT RGB, S-video, or composite video
inputs, depending on the option
selected in the Video output menu.
SA monitor or television with an S-video
input, or a Meridian 562V.2 Multimedia
Controller.
COMPOSITE A television or monitor with a
composite video input, or the
composite video input on a Meridian
562V or 562V.2.
Audio connections
The following tables give details of the alternative audio outputs:
Digital version
Use this output To connect to this
L/R, C/SUB, A digital surround processor with multi-
SURROUND channel digital inputs, or Meridian DSP
loudspeakers.
Video connections
The DVD player provides three alternative video outputs to
provide flexibility in connecting it to other equipment.
If your other equipment provides component video inputs, use
these to produce the highest possible video quality.
The video connections should be made using suitable video
cables, which are available from your dealer.
Component version
Use this output To connect to this
COMPONENT A monitor or projection television with
VIDEO OUT component video inputs, progressive in
the progressive version.
SA monitor or television with an S-video
input, or a Meridian 562V.2 Multimedia
Controller.
COMPOSITE A television or monitor with a
composite video input, or the
composite video input on a Meridian
562V or 562V.2.
