DISC VIDEO OSD
To select the appropriate screen type according to your TV set, one selects the “SETUP/MEMORY” button
from the L53’s front panel. Choose “DISC VIDEO” and select choices that best fit your TV set.
FORMAT
Select between Letter Box 4:3, Pan Scan 4:3, and Wide Screen 16:9 using either the navigation, or the
“ENTER” buttons to select. To save the setting select “Save and Exit”
SIGNAL MODE
Use the navigation or the “ENTER” buttons to select between NTSC, PAL or AUTO depending on your
TV/monitor configuration/type. To save the setting select “Save and Exit”
SCAN TYPE
Use the navigation or the “ENTER” buttons to select between “Interlaced” and “Progressive” scan types,
depending on your TV/monitor configuration/type. To save the setting select “Save and Exit”
NOTE
One can also use the L53’s front panel “DISPLAY:” button to toggle between Progressive and
Interlaced scan. Hold in the “DISPLAY” button for greater than 8 seconds to toggle between the scan
types.
Progressive scan is not available for RGB output.
VIDEO OUTPUT (230V ONLY)
Use the navigation or the “ENTER” buttons to select between RGB (SCART Video Out) and YUV
(Component Video Out) depending on your TV/monitor configuration. To save the setting select “Save
and Exit”
NOTE
RGB is not available when Progressive scan is selected.
DISC AUDIO OSD
Depending on the media played, audio may not be present unless the “AUDIO OUT” is set to either
“PCM” or “Bitstream”. Please refer to your DVD/CD media documentation for the correct settings.
DIGITAL OUT
Select between “PCM” and “Bitstream” at the L53’s “DIGITAL OUT” to other audio/video equipment
using the navigation or the “ENTER” buttons to select. To save the setting select “Save and Exit”
PCM FORMAT
Select between “96kHz” or “96kHz > 48kHz” using the navigation or the“ENTER” buttons to select. To
save the setting select “Save and Exit”
DISC LANGUAGE
Depending on the DVD media, only those languages recorded on the DVD media are available. When
these settings are chosen, they will become default settings, unless the DVD media overrides the settings.
AUDIO
Select between English, French, German, Dutch, Spanish, Italian, Portuguese, Swedish and Original for
the DVD disc audio using the navigation or the “ENTER” button to select. To save the setting select “Save
and Exit”
SUBTITLE
Select between English, French, German, Dutch, Spanish, Italian, Portuguese, Swedish, and OFF for the
DVD disc subtitles using the navigation or the “ENTER” button to select. To save the setting select “Save
and Exit”
MENU
Select between English, French, German, Dutch, Spanish, Italian, Portuguese, Swedish, and Original for
the DVD disc menus using the navigation or the “ENTER” button to select. To save the setting select
“Save and Exit”
USING THE L53’S DVD/VCD/CD PLAYER
Operation
