Reference
AMPLIFIER SECTION
Power output Stereo Mode
1
2 x 50W
Total harmonic distortion at rated power 0.08%
IM distortion at rated power 0.08%
Damping factor 8 ohms > 60
Frequency response 20 to 20,000 Hz ±0.5 dB
Signal/noise ratio
2
>99 dB
Signal/noise ratio
3
>85 dB
Remote control HTR L53
TUNER SECTION
Input sensitivity Mono 16.1 dBf
50dB Stereo 36.1 dBf
Harmonic Distortion FM Mono 0.2%
FM Stereo 0.5%
Signal / noise Mono 69 dB
Stereo 64 dB
Stereo separation at 1 kHz 40 dB
Frequency Response; ± 1.5 dB 30 Hz - 15 kHz
OUTPUTS
Video output 1.0 V (p-p), 75 ohms, negative sync., RCA jack x 2
Component out RCA x 3
S-video output (Y) 1.0 V (p-p), 75 ohms, negative sync.,
Mini DIN 4-pin x 2
(C) 0.286 V (p-p), 75 ohms
SCART video output (EUR only) CVBS 1.0 V (p-p), 75.ohms, negative sync.,
(RGB) 0.63 V (p-p), 75 ohms
Audio output (optical audio) Optical connector x 1
Audio output (analog audio) 2.0 Vrms(1 KHz, 0 dB), 330 ohms,
RCA jack (L, R) x 2
Speaker terminals (+, -) x 2
INPUTS
Audio input (optical audio) Optical connector x 1
Audio input (coxaxial audio) Coaxial connector x 1
Audio input (analog audio) 2.0 Vrms(1 KHz, 0 dB), 330 ohms,
RCA jack (L, R) x 6, (5.1) x 5
Component input RCA jack x3
DVD SECTION
Signal system PAL/NTSC/AUTO)
Laser Semiconductor laser, wavelength 650 nm
Frequency range (audio) 4 Hz to 20 kHz
Signal-to-noise ratio (audio) More than 100 dB (EIAJ)
Dynamic range (audio) More than 95 dB (EIAJ)
Harmonic distortion (audio) 0.008 %
JPEG Baseline < 5120 x 3840 pixels
Progressive < 2048 x 1536 pixels
PHYSICAL SPECIFICATIONS
Dimensions (W x H x D) 17 1/8 x 4 1/8 x 14 3/4”
(435 x 105 x 375mm)
Net Weight 18.5 lbs (8.4 kg)
Shipping Weight 23 lbs (10.5 kg)
1 8 ohms within rated distortion
2 Ref rated power / 8 ohms (A-WTD)
3 Ref 1W / 8 ohms (A-WTD)
Specifications are subject to change without notice. For updated documentation and features please log onto
www.nadelectronics.com for the latest information about your L53.
SPECIFICATIONS
