Specifications
AMPLIFIER SECTION
Power Output (FTC) All channels 30 watts per channel min.
RMS. into 6 ohms two channel driven,
1,000 Hz with no more than 0.6 % total
harmonic distortion.
Continuous power output (DIN)
All channels 30 watts per channel min.
RMS. into 6 ohms two channel driven,
1,000 Hz
Total Harmonic Distortion0.6 % at rated power
0.2 % at 1 watt output
IM Distortion 0.6 % at rated power
0.2 % at 1 watt output
Damping Factor 40 at 8 ohms
Input Sensitivity and Impedance
VIDEO 1 DIGITAL INPUT (OPT) –21 to –15 dBm
VIDEO 2 DIGITAL INPUT (COAX) 0.5 Vp-p, 75 ohms
LINE (VIDEO 1, 2, TV/LINE, TAPE/MD) 200 mV/50 kohms
Composite (VIDEO 1, 2) 1 Vp-p, 75 ohms
S-VIDEO (VIDEO 1, 2) Y: 1 Vp-p, 75 ohms
C: 0.28 Vp-p, 75 ohms
TUNER SECTION
Tuning Range FM: 87.50 to 108.00 MHz (50 kHz steps)
AM: 522 to 1611 kHz (9 kHz steps)
Usable Sensitivity FM: Mono 11.2 dBf, 1.0 µV (75 ohms IHF)
0.9 µV (75 ohms DIN)
Stereo 17.2 dBf, 2.0 µV (75 ohms IHF)
23 µV (75 ohms DIN)
AM: 30 µV
50 dB Quieting Sensitivity FM: Mono 17.2 dBf, 2.0 µV (75 ohms)
Stereo 37.2 dBf, 20.0 µV (75 ohms)
Capture Ratio FM: 2.0 dB
Image Rejection Ratio FM: 85 dB
AM: 40 dB
IF Rejection Ratio FM: 90 dB
AM: 40 dB
Signal-to-noise Ratio FM: Mono 76 dB, IHF
Stereo 70 dB, IHF
AM: 40 dB
Alternate Channel Att. (+/– 400 kHz) FM: Mono 55 dB, IHF
Selectivity FM: 50 dB, DIN
AM Suppression Ratio FM: 50 dB
Harmonic Distortion FM: Mono 0.2 %
Stereo 0.3 %
AM: 0.7 %
Frequency response FM: 30 to 15,000 Hz (+/– 1.0 dB)
Stereo Separation FM: 45 dB at 1,000 Hz
30 dB at 100 to 10,000 Hz
Stereo Threshold FM: 17.2 dBf, 20 µV (75 ohms)
DVD SECTION
Signal readout system Optical non-contact
Linear velocity 3.49 m/s (Single Layer), 3.84 m/s (Dual
Layer)
Error correction system Reed Solomon Product Code
Signal system PAL/3.58 NTSC
Frequency response 4 Hz - 20 kHz (44.1 kHz),
4 Hz - 22 kHz (48 kHz),
4 Hz - 44 kHz (96 kHz)
Wow and flutter Below threshold of measurability
GENERAL
Power Supply Rating AC 230-240 V, 50Hz
Power Consumption 155 W
Specifications and features are subject to change without notice.
Output Level and Impedance
DIGITAL OUTPUT (OPT) –21 to –15 dBm
REC OUT (TAPE/MD, VIDEO 1) 200 mV, 2.2 kohms
PRE OUT (SUBWOOFER) 1 V, 2.2 kohms
Composite (MON OUT, VIDEO 1) 1 Vp-p, 75 ohms
S-VIDEO (MON OUT, VIDEO 1) Y: 1 Vp-p, 75 ohms
C: 0.28 Vp-p, 75 ohms
RGB video output 0.7 Vp-p, 75 ohms
Frequency Response 20 to 30,000 Hz : +/– 0.8 dB
Acoustic Control 1: +6 dB at 40 Hz
2: +10 dB at 55 Hz
+5 dB at 10,000 Hz
Signal-to-noise Ratio 100 dB (IHF)
Muting –∞ dB
Dimensions (W x H x D) 435 × 101 × 428 mm (17
1
/8 × 4 × 16
7
/8 ins.)
Weight 9.2 kg (20.3 lb.)
