Controls and Functions
6 Runco CX-40HD/CX-46HD Owner’s Operating Manual
PRE
L
IMINAR
Y
Crystal Series LCD Display
Inputs and Outputs
Figure 2-2 shows the locations of the Crystal Series LCD Display inputs and outputs.
Figure 2-2. Crystal Series LCD Display Rear-Panel Inputs and Outputs
1. INPUT2 Audio Input
2. INPUT2 Composite Video Input
Standard composite video input for connecting a VCR, camcorder, laser disc player
or other composite video source.
3. INPUT2 S-Video Input
Standard S-Video input for connecting a DVD player, satellite receiver or Super VHS
(S-VHS) VCR.
4. Headphone Jack
5. Main Power Switch
6. Power Input (100 to 240 VAC)
Connect the Crystal Series LCD Display to power here.
7. RGB
A 15-pin VGA connection to a personal computer. The Crystal Series LCD Display
automatically detects the signal resolution.
8. HDMI1/Computer Input (Digital)
➤
L
R
Rear
INPUT2
INPUT4
INPUT3
INPUT4
INPUT3
INPUT1
INPUT1
S-VIDEO
VIDEO
Audio
Right Side
