18 Runco CX-40HD/CX-46HD Owner’s Operating Manual
PRE
L
IMINAR
Y
RGB Connections: The Crystal Series LCD Display has an RGB input for connecting a
personal computer; see
Figure 3-3.
Figure 3-3. Analog RGB Connections
1. Refer to Computer Signal Compatibility on page 61 for a list of
computer signals compatible with the Crystal Series LCD Display.
Use with signals other than those listed may cause some functions
not to work.
2. Some Macintosh computers may require a Macintosh video
adapter. Contact your nearest authorized service center or dealer.
3. This Crystal Series LCD Display may not be able to display images
from notebook computers in simultaneous (CRT/LCD) mode.
Should this occur, switch the notebook computer to “CRT only”
mode. If you are unsure how to do this, refer to your notebook
computer’s user manual.
INPU
INPUT3
Audio Cable
(Sold Separately)
D-Sub 15 Pin Cable (Sold Separately)
Rear of the Display Rear of the PC
Note
