Runco CX-40HD/CX-46HD Owner’s Operating Manual 27
PRE
L
IMINAR
Y
4.4
Using the On-Screen
Menus
To use the on-screen menus:
1. Press MENU to display the Main Menu.
2. To select a menu item, use the up- or down-arrow buttons ( , ) on the remote
control to highlight it.
3. Press ENTER or the right-arrow button ( ) to access that menu.
4. Use the up- or down-arrow buttons ( , ) to select the setting you want to change.
Then, press ENTER or the right-arrow button ( ).
5. Press the right- or left-arrow button ( , ) to change that setting.
6. To return to the previous menu, press MENU.
The Crystal Series LCD Display OSD menus are arranged hierarchically, as shown in
Figure 4-1. Depending on the selected input source and/or signal characteristics, some
menu options may not be available.
1. The maximum available resolution and vertical frequency is
1600x1200/60Hz (RGB), 1280x1024/60Hz (HDMI) or the
maximum supported by your video card, whichever is lower. You
can get the best picture at 1024x768/60Hz.
2. The Crystal Series LCD Display supports 24-bit color
(16,777,216 possible colors).
Note
