English - 86
Specifi cations
General
Power requirements 120V AC, 60Hz
Power consumption 28 Watts
Weight 7.12lb
Dimensions 16.9 in(W) x 12in(D) x 2.3in(H)
Operating temp. +41°F to +95°F
Other conditions Keep level when operating. Less than 75% operating humidity
Input
Broadcasting standard NTSC, ATSC
Band coverage Air 2 ~ 69, Cable 1 ~ 135
Video (1,2) 1.0 V p-p at 75Ω load, sync negative
S-Video input (Y: 1.0Vp-p, C: 0.286Vp-p at 75Ω load)
Audio(1,2) Max.Audio Input Level : 2Vrms
DV Input IEEE 1394(4p) compatible jack
Output
Audio
Analog output jacks 1, 2
Optical/Coaxial digital audio output
Full scale Analog output level : 2Vrms
Video
Video output jack
S-Video output (Y:1.0Vp-p, C:0.286Vp-p at 75Ω load)
Component output (Y: 1.0Vp-p, Pb: 0.70Vp-p, Pr: 0.70Vp-p at
75Ω load)
HDMI output (480p, 720p, 1080i)
Recording
Picture Compression format MPEG-II
Audio Compression format Dolby Digital 2ch/256kbps
Recording Quality
XP (about 8 Mbps), SP (about 4 Mbps), LP (about 2 Mbps),
EP (about 1.2 Mbps or about 0.8 Mbps)
Audio Frequency Response 20 Hz ~ 20 kHz
Audio Output
Disc Type DVD AUDIO CD(CDDA)
Analog Audio Output 48 / 96kHz 44.1kHz
Digital Audio Output 48kHz 44.1kHz
For DVD discs, audio signals recorded at 96kHz sampling
frequency are converted and output at 48kHz.
