DVR Viewer2 Operation Guide3
English 13
The image files are not displayed when the Viewer Software is run. Specify and open the playback file through the procedure
below.
1 Click in the toolbar.
Or, click “Open” in the file menu.
The [Open] dialog is displayed.
2 Click .
The [Browse for Folder] dialog is displayed.
3 Specify the folder in which the images
are saved and click [OK].
The folder specified in the [Open] dialog is displayed.
4 Verify the displayed folder and click
[OK].
The image file loads.
5 Screen display
The first image of the loaded file is initially displayed on full
screen.
Refer to the appropriate pages for details about the
operations of the Viewer Screen.
z Switching the display pattern (1/4/9/16 screen) of the
playback images (Refer to P14)
z Selecting the channels displayed on each screen (Refer
to P14)
z Operating panel functions (Refer to P15)
Opening Image Files
01 09/29/2005 16:28:24
