Additions and Changes to Main Unit Operating Procedures1
English 5
Now you can forcibly interrupt the current recording session
while the <MAIN MENU> screen is displayed. Using this
feature, you can change the menu settings without changing
the current recording conditions.
z To interrupt the current recording session:
Press and hold the [SHUTTLE HOLD] button for about 3
seconds.
☞ The recording indicator turns off, and all the recording
mechanisms (normal, timer, and alarm) are switched to
pause mode. During pause, you can change the menu
settings.
z To exit from pause mode:
Press the [EXIT/OSD] button.
☞ You are returned to the same recording status as before
you paused the recording session.
z While recording is paused, the DVR does not accept any
new recording command.
z If, with the recording session paused, you have
uploaded a menu setting file or a power failure has
occurred, the DVR does not resume the previous
recording status.
The following changes have been added to the “MON.2
DISPLAY” item on the <ALARM OPERATION SET> screen
under “RECORD SET”.
[Settings] (
indicates default setting)
Forcible Interruption of Recording (P58)
<--> <MAIN MENU>
1.INITIAL SET ->
2.RECORD SET ->
3.GENERAL SET ->
4.SCREEN SET ->
5.POWER LOSS/USED TIME ->
6.INITIALIZATION LOG ->
7.COPY MENU SETTINGS ->
8.ADVANCED MENU SET ->
MOVE:JOG SELECT:SHUTTLE
While the recording session is paused,
a <--> mark is displayed on the menu screen.
Changes to the Display of Monitor 2 upon
Alarm Detection (P104)
Setting Description
NC
When an alarm is detected, the main monitor
does not change.
SWITCH
(added)
When a number of alarms occur, the display
switches between the video from the
corresponding cameras, showing each for one
second.
9
When an alarm is detected, the main monitor
appears in multi 9 screen display.
16
When an alarm is detected, the main monitor
appears in multi 16 screen display.
LAST
(added)
When a number of alarms occur, the most recent
alarm video is given priority and is displayed.
FIRST
(added)
When a number of alarms occur, only the video
for the first alarm is displayed. However, if the
duration for the first alarm expires, video for the
next alarm is displayed.
<ALARM OPERATION SET>
ALARM RETRIGGER : ON
MAIN MON. DISPLAY : FULL
ALARM PRIORITY : LAST
MON.2 DISPLAY : NC
(Settings changed)
