16 English
DVR Viewer2 Operation Guide3
To save or print the image currently being displayed, switch
to “Full screen display” and perform the following
operations.
Click in the toolbar or “Save” in the File menu.
The save dialog appears.
Specify the destination folder and file and click [OK]. The
image on the Viewer screen is saved in the bitmap format.
Click in the toolbar or click “Print” in the File menu.
The print dialog appears.
Set the printing conditions and click [OK]. The image on the
Viewer screen is printed full size.
Click “Title Input” in the File menu.
The “Title Input” dialog appears. Type the title to be printed
in the input box and click [OK]. The title is displayed at the
bottom of the image when it is printed.
z The ten most recent input titles are saved which allows
you to choose a title using the pull down menu.
Clicking the “Date Display Format” will display the [Date
Display Format] dialog. Set the format and delimiter and
click [Apply] and then [OK].
1 Display format (
indicates default setting)
To set the date display format.
Selections:
MM/dd/yyyy (Month/Day/Year)
dd/MM/yyyy (Day/Month/Year)
yyyy/MM/dd (Year/Month/Day)
2 Delimiter (
indicates default setting)
Selections: / (Slash), - (Hyphen), . (Period)
3 Sample
When you change the display format or delimiter and
click [Apply], the sample (preview) is updated with the
new settings.
Saving and Printing Images
Saving images
Printing Images
Displaying a Title on the Image that is Printed
Setting the Date and Time Display Format
1
3
2
