TL H.264 DVR User’s Manual
68
5.4.4 Per Camera Configuration
This sub-menu is used to set the Day / Night / Weekend PPS and recording
quality for each individual channel. <Preset Configuration> must be set to
<OFF> in order to access these related settings. The menu is displayed as
below in Record mode: 720×240@120PPS in NTSC / 720×288@100PPS in
PAL (for DVR-16TL).
Per Camera Config
Cameral Select
Normal PPS
Normal Qlty
Event Max PPS
Event Qlty
Event Act
Day
7.5
Mid
30
Best
Both
Night
7.5
Mid
30
Best
Both
CH1
Weekend
7.5
Mid
30
Best
Both
5.4.4.1 Camera Select
The item is used to select a desired channel for setting the parameters. Move
the cursor to <Camera Select> and press ENTER, then select a channel
using UP / DOWN keys. Press ENTER again to confirm the selection.
5.4.4.2 Normal PPS
Normal PPS is used to set the recording rate for normal status.
Please note that the total normal PPS of all channels cannot exceed the
maximum PPS of each Record mode. To increase one channel’s PPS, others’
may have to be reduced first. Event PPS is not restricted to this rule, since a
smart event scheduler will handle to the total PPS with a correct weighting.
For example, if channel 1 is set to event mode with 30PPS, the remaining 30
PPS will be equally distributed to other 15 channels, which means each
channel will be set to 2 PPS.
5.4.4.3 Normal Qlty
This item is used to set the picture size for normal status recording. The
available options are: <Low>, <Fair>, <Mid>, <High> and <Best>.
5.4.4.4 Event Max PPS
<Event Max PPS> is used to set the event recording rate for Event status.
Usually, the Event PPS is set equal to or greater than the Normal PPS. The
setting is depending on users’ application. If the Event PPS is set to <0>,
DVR-4TL/8TL/16TL will not record event video when alarms triggered.
