Specifications
Ratings
8
Recording media
microSD card (64 MB−2 GB)
microSDHC card (4 GB−32 GB)
8
Recording/playback formats
WAV: 44.1/48/96kHz, 16/24 bit
MP3: 44.1/48 kHz, 32/64/96/128/192/256/320 kbps
8
Number of channels
2 channels (stereo)
Inputs and outputs
8
MIC/EXT IN jack (can provide plug-in
power)
Connector: 1/8” (3.5mm) stereo mini jack
8
/LINE OUT jack
Connector: 1/8” (3.5mm) stereo mini jack
8
Built-in speaker
0.3W (mono)
8
Control input/output ratings
8
USB port
Connector: Mini-B type
Format: USB 2.0 HIGH SPEED mass storage class
Audio performance
8
Frequency response
20-20 kHz +1/−3 dB
(EXT IN to LINE OUT, 44.1kHz sampling frequency, JEITA*)
20-22 kHz +1/−3 dB
(EXT IN to LINE OUT, 48kHz sampling frequency, JEITA*)
20-40 kHz +1/−3 dB
(EXT IN to LINE OUT, 96kHz sampling frequency, JEITA*)
8
Distortion
0.05% or less
(EXT IN to LINE OUT, 44.1/48/96kHz sampling frequency,
JEITA*)
8
S/N ratio
92 dB or higher
(EXT IN to LINE OUT, 44.1/48/96kHz sampling frequency,
JEITA*)
*based on JEITA CP-2150
Recording times
File format (recording setting)
Capacity
4 GB
WAV 16-bit (STEREO) 44.1kHz 6:44:00
WAV 24-bit (STEREO) 96kHz 2:04:00
MP3 (STEREO/MONO)
320kbps
44.1kHz
48kHz
29:48:00
•
The recording times shown above are estimates. They might
differ depending on the microSD/microSDHC card in use.
•
The recording times shown above are not continuous
recording times, but rather they are the total possible
recording times for the microSD/microSDHC card.
Requirements for connected
computers
Check the TASCAM website (http://tascam.com/) for the latest
information about supported operating systems.
8
Supported operating systems
Windows: Windows XP, Windows Vista, Windows 7,
Windows 8 (including 8.1)
Macintosh: Mac OS X 10.2 or newer
General
8
Power
2 AA batteries (alkaline or NiMH)
USB bus power from a computer
AC adapter (TASCAM PS-P515U, sold separately)
8
Power consumption
1.7 W (maximum)
8
Battery operation time (continuous
operation)
•
Using alkaline batteries (EVOLTA)
Format
Operation
time
Note
Recording
WAV, 44.1kHz,
16-bit
About 17.5
hours
Recording with
built-in mic
Playback
WAV, 44.1kHz,
16-bit
About 19.5
hours
Using built-in
speaker
Recording: JEITA recording time
Playback: JEITA music playback time
•
Using NiMH battery (eneloop)
Format
Operation
time
Note
Recording
WAV, 44.1kHz,
16-bit
About 15.5
hours
Recording with
built-in mic
Playback
WAV, 44.1kHz,
16-bit
About 16.5
hours
Using built-in
speaker
Recording: JEITA recording time
Playback: JEITA music playback time
8
Dimensions (W × H × D)
61 × 141 × 26 mm
8
Weight
116 g (not including batteries)
8
Operating temperature range
0°C–40°C (32°F–104°F)
•
Illustrations in this manual might differ in part from the
actual product.
•
Specifications and external appearance might be changed
without notification to improve the product.
•
Detailed specifications are provided in the Reference
Manual.
