Toshiba DKVR60KU DVD Recorder User Manual



16 EN16 EN
Video Info. : 480p / YCbCr
Audio Info. : Bitstream
21
33
1. Indicates the resolution of the HDMI output image.
2. Indicates the HDMI video format.
3. Indicates the HDMI audio format.
“- - -” will be displayed, when it does not have any
information.
HDMI Information
GUIDE TO ON-SCREEN DISPLAYS AND MENUS
Title name information
Title Name
My Title
File name information
File Name
My File
Title/File Name Information
• First, track name will be displayed.
Track Name
• If you press [DISPLAY] one more time, artist name will
be displayed.
Artist Name
• If you press [DISPLAY] one more time, album name
will be displayed.
Album Name
• If there is no artist, track or album name, “Not Available”
will be displayed.
MP3/WMA Tag Information
VCR mode
0:00:00 HIFISP
12:00AM
4 53
2
1
* This is an example screen only for explanation.
1. Indicates current video status.
2. Indicates the current time.
3. Indicates a recording or playing back mode.
4. Indicates a tape counter.
5. Audio status of the current cassette tape.
VCR Information
Note
• VCR information does not appear on the screen
when the unit is connected by an HDMI,Component
or S-Video cable, except during the playback.
