45EN 45EN
Disc
Management
Recording
PlaybackIntroduction Connections Basic Setup Editing Function Setup VCR Function Others
SETTINGS FOR AN EXTERNAL DEVICE
HDMI OUT
TRACKING
DUBBING SELECT
VCR DVD
VIDEO L R DV IN
L2 L3
IN
L
R
L
R
S-V ID EO IN --- AU D IO --- OU T
IN --- V I DE O --- OU T
(L1)
DIGITAL
AUDIO OUT
AUDIO
OUT
S-VIDEO
OUT
COAXIAL
L
R
Y
P
B
/CB
PR
/CR
COMPONENT
VIDEO OUT
DVD/VCR
IN
L
R
L
R
S-VIDEO I N --- AUD IO --- OU T
IN --- VIDE O --- OU T
AUDIO OUT DV-OUT
LR
VIDEO
OUT
AUDIO OUT
LR
VIDEO
OUT
S-VIDEO
OUT
VIDEO L R DV IN
L2 L3
front of this unit
rear of this unit
external device
(camcorder, VCR etc.)
DV cable
(4-pin)
RCA
video
cable
RCA
audio
cable
to L2 & L3
or
to L1
S-video
cable
RCA
video
cable
RCA
audio cable
or
L2 L3
L1
(L1)
or
Supplied cables used in this connection are as follows:
• RCA audio cable (L/R) x 1
• RCA video cable x 1
Please purchase the rest of the necessary cables at your local store.
Connect the external device properly to the unit by using input jacks either L2 (Front) or L1 (Rear).
When connecting an external device of monaural output to this unit, use AUDIO L jack of L2 (Front).
Use S-video or the RCA audio/video cables for this connection.
When connecting a DVC (digital video camcorder), it is recommended to connect the DVC with the front DV IN jack
with a commercially available mini DV/Firewire cable.
Connection to an External Device
