VIZIO VU42L FHDTV10A User Manual
Version 12/17/2007 17
www.VIZIO.com
2.2 Connecting Your Cable or Satellite Box
2.2.1 Using HDMI
Cable and Satellite Boxes that have a HDMI digital interface should be connected to the HDMI input of
the LCD HDTV for optimal results.
Connecting your Cable or Satellite Box (Best)
1. Turn off the power to the LCD HDTV and HDTV Set-Top Box.
2. Connect a HDMI cable to the HDMI output of your HDTV Set-Top Box and the other end to
the HDMI Input (white color area) at the rear of the LCD HDTV.
3. Turn on the power to the LCD HDTV and HDTV Set-Top Box.
4. Select HDMI using the INPUT button on the remote or side of the LCD HDTV, or directly by
pressing the HDMI button on the Remote Control.
Note: To maintain the display quality, use a VIZIO certified HDMI cable that is 10 meters or less. See
www.vizio.com
or call 1-888-VIZIOCE (1-888-849-4623) for details.
Note:
c) The HDMI input on the LCD TV supports High-bandwidth Digital Content Protection
(HDCP). HDCP encrypts the transmission between the video source and the digital display
for added security and protection.
d) If you are already using the HDMI 1 input for another component, or you do not want to use
the HDMI 1 input for the Set-Top Box, you can connect the Set-Top Box to the HDMI 2
connection.
e) Refer to your HDTV Set-Top Box user manual for more information about the video output
requirements of the product or consult your cable or satellite operator.
