VIZIO VU42L FHDTV10A User Manual
Version 12/17/2007 9
www.VIZIO.com
Chapter 1 Basic Controls and Connections
1.1 Front Bezel
Power ‘VIZIO’ light – The VIZIO name lights white when
powered on and orange when powered off.
Remote Control Sensor – This is the window through
which all of the remote control signals pass to the sensor.
Point the remote control directly at this window for the best
response to the remote signal.
1.2 Right Side Panel Controls
Power ( ) – Switch the VU42L FHDTV10A on by pressing
the button once. Press the button again to the VU42L
FHDTV10A off.
Menu – This button activates the On Screen Display (OSD). If a
sub-menu is active, pressing this button will return to the
previous menu level.
Channel ▲/▼ – Use these buttons to step up or down the TV
channels. While the OSD is active, these buttons function as up
and down controls in the OSD menus.
Volume ◄/► – Use these buttons to increase or decrease to the
speaker volume. While the OSD is active, these buttons function
as left and right controls in the OSD menus.
Input (Enter) – Repeated pressing of this buttons steps through
the input sources in the following sequence: TV, AV1 (S-Video or
Video), AV2, Component 1, Component 2, RGB, HDMI 1 and
HDMI 2. Once you have stepped through the entire sequence,
you will return to the beginning.
Additionally, when the OSD is active, this button confirms the
menu function to be adjusted. When the OSD is not active,
pressing this button will display the current input mode.
