APPENDIX B
FRONT PANEL DISPLAY
B.1 HOME SCREEN
If there is no current alarm or warning condition, and the unit is NOT inserting, the following
home screen will be shown:
P O R T : x R A T E : y y . y y y
P R O G : z z z z z z z z z
PORT: x is the ASI input port, either 1 or 2
RATE: yyyyy.yy is the input data rate,
PROG: zzzzzz is the program number (up to 5 digits)
If alarm or warning condition is active:
A L A R M
m s g
or
W A R N I N G :
m s g
MSG: msg is a string identifying the condition. See Section 3.2 (Page 30) for warning and
alarm conditions.
If unit is inserting:
P O R T : x R A T E : y y . y y y
P R O G : z z z z z z z z z T E M P
PORT: x is the ASI input port,
RATE: yyyyy.yy is the input data rate,
PROG: zzzzzz is the program number (5 digits), and
TEMP: if this is output, the unit is inserting.
B.2 UNIT SERIAL NUMBER
To provide easy access to the unit’s serial number, press <ENTER> from the Home Screen to
display the serial number for approximately 2 seconds.
