8x8 and 16x16 VGA / HDTV Matrix Switch with Audio, RS232 & IP Control
29
4.2.2 Shipping and Packaging
If you need to transport or ship your matrix:
• Package it carefully. We recommend that you use the original container.
• Before you ship the unit back to Black Box for repair or return, contact us to
get a Return Authorization (RA) number.
5.0 Specifications
Video Inputs 8 or 16 HD15 female connectors
Video Outputs 8 or 16 HD15 female connectors
Resolutions Supported PC resolutions up to 1900x1200 @ 60 Hz & HDTV to
1080p
Video Levels -0.3v to 0.7v (1 V p-p) on RGB, 0 to 5v DC on Sync
Audio Inputs Unbalanced Stereo.
Audio Input Levels 0 to +4dBu (0.78 to 1.23Vrms) line level
Audio outputs Balanced Stereo on screw terminals.
Audio Bandwidth 10 Hz to > 10 MHz (could pass through analog or
digital S/PDIF audio sources)
Temperature Operating: 32 to 122°F (0 to 50°C);
Storage: –40 to +185°F (–40 to +85°C)
Enclosure Steel with Aluminum front panel
Battery Type CR2032 (3v Lithium)
MTBF 90,000 hours (calculated estimate)
Power 100VAC-240VAC 50/60Hz.
Size 3.5" High x 19" Wide 12.78” Deep
Weight 9.4 pounds
