PROTOCOL CONVERTER MODEL A/S-4
36
6.9 Changing Keys Arrangements on a Particular Keyboard Layout Type
Selection of item F from the main menu will cause the menu shown in Figure 9 to be displayed.
CURRENT:
Application = SDLC/SNA 3274/76 Interactive
VDU = ANSI STD; DEC VT100; Teletype 5410, 5420; Televideo 970, 960
Keyboard = STANDARD
A-Exit
B-PF Keys
C-PA Keys
D-Command Keys
E-IBM Keys
F-PROTOCOL CONVERTER Keys
Enter Letter:
Figure 9
This menu allows for great flexibility in keyboard layouts. If you desire you may alter Key assignments or
design your own keyboard layout. The selections available from this menu is as follows:
Exit Go back to main menu
PF Keys Programmable function keys
PA Keys Programmable attention keys
Command Keys Keys used for editing & cursor movement (e.g., Clear)
IBM Keys Keys used to perform IBM terminal operations (e.g., Field Mark)
Protocol Keys used to control the A/S-4’s operation
Converter Keys (e.g., Restart A/S-4, which will take operator back to main menu)
The keys arrangement can only be changed if the current keyboard is a programmable keyboard (see
Section 6.8)
