PROTOCOL CONVERTER MODEL A/S-4
58
8.4 Batch Default Options
The A/S-4 has the capability of loading all it’s Batch options from the VDU (computer) without going
through any menus. This is done by receiving the shift out (X’0E;) character followed by the options
selected in hexadecimal form. The VDU and A/S-4 must be set to receive and transmit an 8-data bit
word with no parity, so all 8 bits of the hexadecimal characters are received. Once all the new Batch
default options are loaded, the A/S-4 is then automatically set to run in the Batch 3776/77 mode. Below
is the Batch options with its bit location.
BYTE DEFAULT
*** SDLC (MODEM) PORT OPTIONS ***
1 17 BIT 7 -
6 -
5 & 4 - 00=ASYNC, 01=SYNC
3 THRU 0 = BAUD RATE
0101 = 300 1100 = 4800
0110 = 600 1110 = 9600
0111 = 1200 1111 = 19.2K
1010 = 2400
2 0C BIT 5 & 4 - STOP BITS: 00=SYNC, 01=1, 10=1.5, 11=2
3 & 2 - WORD LENGTH: 10=7, 11=8
1 & 0 - PARITY: X0=NONE, 01=ODD, 11=EVEN
3 00 BIT 6 & 5 - XON/OFF: 00=OFF, 01=FROM VDU, 10=TO VDU,
11=BOTH
1 & 0 - CHAR CODE: 00=EBCDIC, 01=ASCII
4 F7 SDLC PU ADDRESS
5 80 CUSTOMER OPTIONS A
6 02 CUSTOMER OPTIONS B
7 01 PROTOCOL, 00=3274/76, 01=3776/66
8 30 SDLC 3770 XID
90F
10 FF
*** ASYNC (TERMINAL) PORT OPTIONS ***
*** INBOUND (VDU) LU ***
11 07 ASYNC BAUD RATE (1200 BAUD) SEE BYTE 1
12 0C WORD LENGTH: 8 - DATA BITS, NO PARITY SEE
BYTE 2
13 01 CHAR OPTION: XON/OFF=OFF, ASCII CHARACTERS
