DVD+VCR User’s Guide
1 DVD DECK
Deck used for DVD/CD playback and other
DVD functions.
2 DVD OPEN/CLOSE
Press to open and close the DVD disc
drawer.
3 VCR DECK
Deck used for VCR playback and other VCR
functions.
4 RECORD
Press to start recording in the VCR deck.
Press repeatedly to add recording time in
30-minute increments (see page 22).
5 VCR EJECT
Press to eject the VHS tape from the VCR
deck.
6 POWER
Press to power the DVD+VCR on and off.
7 DVD - SKIP/SEARCH BACK
While a DVD is playing, press once to return
to the previous track. Press and hold to
search in reverse.
VCR - REWIND
While a VHS tape is stopped, press to
rewind the tape. While a tape is playing,
press to review the tape (visual search in
reverse).
1
6 7 8 9 10 11 12
13
2345
The following is an overview of the
DVD+VCR front panel.
FRONT PANEL
8 PLAY/PAUSE
Press to start playback in the active deck.
Press again to pause playback. Also used to
pause recording in the VCR deck.
9 STOP
Press to stop playback in the active deck.
10 DVD - SKIP/SEARCH FORWARD
While a DVD is playing, press once to
advance to the next track. Press and hold to
search forward.
VCR - FAST-FORWARD
While a VHS tape is stopped, press to fast-
forward the tape. While a tape is playing,
press to cue the tape (visual search forward).
11 DVD-VHS SELECT
Press to toggle control between the DVD
deck and the VCR deck.
12 FRONT PANEL DISPLAY
Displays information pertaining to
DVD+VCR operation.
13 FLAP DOOR
The front panel flap door opens to reveal
additional keys, as well as the front line
audio/video inputs (see next page).
