Appendix D - Help
TECHNICAL SPECIFICATIONS
The following are the technical specifications for your DVD+VCR.
INPUTS
AUDIO 2 Stereo audio inputs, RCA Connector, -8dbm, 47KΩ, front
and rear
VIDEO 2 Composite video inputs, RCA Connector, 75Ω, 1Vp-p
RF Antenna or CATV Input, F-Connector, 75Ω – Ch 2-69, CATV
Ch 1-125
OUTPUTS
AUDIO 2 Stereo audio outputs, RCA Connector, -8dbm, 1.5kΩ
VIDEO DVD+VCR: 1 Composite video output, RCA Connector, 75Ω,
1Vp-p
DVD only: 1 S-Video output, S-Connector, 75Ω, Y = 1.0Vp-p,
C = 0.286Vp-p
DVD only: 1 Component video output, 75Ω, Y = 1.0Vp-p, Pb
= 0.7Vp-p, Pr = 0.7Vp-p
RF Channel 3 or 4
VCR SPECIFICATIONS
VIDEO SYSTEM 1/2-inch VHS system, 4 rotary head helical scanning; FM
azimuth luminance; chrominance: converted sub system
phase shift
AUDIO TRACK Normal: 1 track; Hi-Fi: 2 track
PLAY/RECORD TIME T-180 tape: SP 3 hours, SLP 9 hours
FF/REW TIME T-120 tape: <2 minutes
HEADS
Video: DA 4 rotary
Audio: 2 rotary heads (Hi-Fi); 1 stationary head (Linear)
Control: 1 stationary head
Erase: 1 full track, 1 audio track
WOW & FLUTTER Less than 0.005% (Hi-Fi)
FREQ. RESPONSE 20-20,000 Hz (Hi-Fi)
DVD SPECIFICATIONS
DISC COMPATIBILITY DVD-Video, CD-Digital Audio (5” and 3.5”), CD-Video
Not compatible with CD-R/W, CD-R
FREQ. RESPONSE 96/48 kHz Sampling: 4 Hz-22kHz
S/N RATIO 110 dB
DYNAMIC RANGE 96 dB
THD 0.003 %
SYSTEM SPECIFICATIONS
POWER REQUIREMENT 120V AC, 60 Hz, 27 watts
CLOCK BACKUP TIME ~6 hours
ENVIRONMENT 41-104 F (5-40 C); 10%-75% humidity
UNIT WEIGHT 11.6 lbs.
UNIT DIMENSIONS 17in. X 14in. X 4in.
