EN 37
Stereo And SAP
(Second Audio Program)
Your VCR’s built-in MTS decoder enables reception of Multi-
channel TV Sound broadcasts.
When the channel is changed on the VCR ...
● The "STEREO" indication appears on the screen for about 5
seconds if the program is a stereo broadcast.
● The "SAP" indication appears on the screen for about 5
seconds if the program is a SAP broadcast.
● Both indications appear when a stereo program is
accompanied by SAP audio.
To Record Stereo Programs . . .
. . . simply follow the basic recording procedure.
To Listen To Stereo Soundtrack During Recording . . .
. . . press A. MONITOR to select "HI-FI" (੬ pg. 29).
NOTES:
●
If a SAP program is received and "2ND AUDIO RECORD" is
set to "ON", the SAP audio is recorded on both the Normal
and Hi-Fi tracks. The main audio program is not recorded.
●
If a non-SAP program is received, the main audio is recorded
on both the Hi-Fi and Normal audio tracks.
To Record SAP Programs . . .
ACCESS MAIN MENU
SCREEN
1
Press MENU.
ACCESS MODE SET
SCREEN
2
Move the highlight bar (arrow) to "MODE SET" by
pressing CH5∞ or %fi, then press OK or
#
.
SELECT 2ND AUDIO
RECORD SET MODE
3
Move the highlight bar
(arrow) to "2ND AUDIO
RECORD" by pressing
CH5∞ or%fi, then press
OK or
#
to set to "ON".
RETURN TO NORMAL
SCREEN
4
Press MENU.
Retake (VHS deck only)
You can cut out unnecessary parts of a TV program while you're
recording it.
ENGAGE RECORD-PAUSE
MODE
1
Press PAUSE during recording.
LOCATE START POINT
2
Hold down REW or FF and release it when you reach
the point where you want to resume recording.
* Your recorder returns to the Record-Pause mode.
RESUME RECORDING
3
Press PLAY when you wish to resume recording.
End of program
Program
Beginning of program
Program
Recorded part
Go back to end of program to cut out
unnecessary part
Unnecessary
part
Unnecessary
part
● VHS/S-VHS
To prevent accidental recording on a recorded cassette,
remove its safety tab. To record on it later, cover the hole
with adhesive tape.
● Mini DV
To prevent accidental recording on a recorded cassette,
set its erase protection switch to "SAVE". To record on it
later, set the switch to "REC".
Record safety tab
Accidental erasure prevention
Erase protection
switch
MODE SET
REAR AUX INPUT VIDEO
FRONT AUX INPUT VIDEO
OUTPUT1 AUTO
= 2ND AUDIO RECORD ON
AUTO TIMER OFF
SUPERIMPOSE ON
SELECT WITH (5,∞) AND (OK)
PRESS (MENU) TO END
