Connect Loewe DVD Preceiver Auro 8116
DT and Tremo loudspeaker system
You can play audio signals from the TV or DVD player in cinema quality
with these components. The Tremo system includes 5 speakers for the front,
center and surround reproduction in addition to the subwoofer illustrated
below. The center signal can be reproduced alternatively by the TV speakers.
Connect the cubic socket on the DVD Preceiver to the “Master” cubic socket
on the subwoofer. Use the cubic plug cable enclosed with the DVD Pre-
ceiver. Plug the white plug (without kink protection) into the cubic socket
on the subwoofer For TV as a center loudspeaker connect “AUDIO IN C” on
the TV set to “PRE OUT C”on the DVD Preceiver with a cinch cable.
Connect the digital audio output of the TV set “AUDIO DIGITAL OUT” to
the “DIGITAL IN” input of the preceiver with a cinch cable. Connect the TV
socket “SERVICE“ to the TV-L-Link socket on the Preceiver with the L-Link
cable (provided with the Preceiver). Switch on the TV set and the Preceiver.
Via the L-Link the TV recognizes whether the Preceiver is connected.
Select the “Tremo“ loudspeaker system in the DVD menu of the Preceiver,
set the listener/speaker distances and adjust the speaker levels. Please
consult the DVD Preceiver manual.
If you want to listen to the sound over the TV speakers temporarily, call the
Sound menu, select “Sound via“ and then “TV“. If you want to listen to the
sound over the Loewe Auro system, select “Auro“ under “Sound“.
Operating additional equipment
ON
Line IN
Power OUT
OFF
Bass Intensity
Center to
System connector
230V~50/60Hz
Surr.
Front
Right
Surr.
Front
Subw.
Left
Right
Center
Left
Slave
Master
R
R
L
C
L
Phase
Min. Max.
TV
Sat
0 180
PREOUT
FR
FL
SL SR SUB
C
TO TV
TV
EXT
12V/15mA
L-Link
AMGND FM (75 Ω)
LL
RR
AUX1 IN
DIGITAL
IN
DIGITAL
OUT
AUX OUTAUX 2
C
OUT
AUDIO
DIGITAL
Service
AV2
